SOLUTIONS
DCP1000 Data Capture and Playback Card
The DCP1000 is a compact and user-friendly Data Capture and Playback Card for mmWave Radars applications, built on the Lattice Nexus platform and featuring the CertusPro-NX with upto 100K logic cells & DDR4 support.
- Built on the Lattice CertusPro-NX FPGA
- Supports LPDDR4 memory up to 2GB with a 32-bit data width
- QT-based GUI for the Host PC communication
- Captures Raw ADC Data over LVDS from AWR/IWR Radar Sensors
- Radar Data playback over DMM/Trace interface
- Parses and visualizes processed data after playback
- SPI and I2C serial interfaces for configuration
and controls; 1Gbps Ethernet with RJ45 port
DCA1000EVM
The DCA1000 EVM provides real-time data capture and streaming for two- and four-lane low-voltage differential signalling (LVDS) traffic
from TI AWR and IWR radar sensor EVMs.
- Based on Lattice ECP5UM
- Supports lab and mobile collection scenarios
- Captures LVDS data from AWR/IWR radar sensors
- FPGA Cores developed – LVDS receiver, Data segregator, DDR3 controller user logic, UDP command decoder, DMM playback and I2C master controller
- Streams output in real time through 1-Gbps Ethernet
- Controlled via onboard switches or GUI/library
- Lattice IPs used – Ethernet TSMAC and
DDR3 controller
Embedded Vision Solutions
Mistral can help customers develop embedded vision solutions for futuristic Industrial display systems ideal for M2M applications,
implementation of Industry 4.0, ADAS, industrial automation, and infotainment applications.
We help our customers create power-efficient solutions for Embedded Vision Processing at the Edge.
- Sensor Integration/Bridging Solutions
- MIPI CSI and DSI based Solutions
- ISP implementation on Lattice FPGAs
- Proof of Concept Development
- PoC to Custom Solution Development
- Solutions based on HDR-60 Video Camera Development Kit
SensAI based Solutions
Lattice SensAI stack provides everything you need to evaluate, develop and deploy FPGA-based Machine Learning and Artificial Intelligence solutions.
Mistral’s expertise on CrossLink-NX, CertusPro-NX, MACHXO3, ECP5 / ECP5-5G and iCE40 UltraPlus platforms enable us offer highly flexible machine learning solutions
for a wide range of Edge applications including portable gadgets, smart home, smart city, Industry 4.0, Autonomous Cars, etc.
- LVDS to CSI converter
- Lattice Crosslink based solutions
- Reference Designs
- Industrial Control Applications
- Test systems to monitor the failure points of Automotive parts
using camera-based data. - Migrate ML/DL functions into Lattice FPGA
through CNN compact accelerator
Custom Design Services
Mistral offers a comprehensive range of custom hardware design and FPGA development services on Lattice FPGAs, tailored to accelerate product development and reduce time-to-market for customers in Automotive, Industrial, Aerospace, and Defence sectors.
Our services include,
- Carrier Boards, Proof of Concept & Product Design
- Custom IP and logic design using Verilog/VHDL
- ML/DL, DSP Algorithm Development and Integration
- Waveform generators and PWM Motor Control applications
- Data Streaming over high-speed protocols
- TI mmWave Radar Data capture & playback
- Camera and Radar sensor fusion solutions
- Image processing for machine vision
- High-speed ADC Processing
APPLICATIONS
Edge Camera Solutions
Machine Learning
Machine Vision
Smart Home
Medical Electronics
Robotics
Virtual Reality systems
ADAS
Drones
Process Control
Autonomous Vehicles
Defence Systems
Sensor Applications
