ANSYS SCADE Display

Design robust embedded displays for human machine interfaces with native support for the OpenGL® SC1 & SC2 (Safety Critical) and ES1 & ES2 (Embedded system) standards

Overview

SCADE Display is part of the ANSYS Embedded Software family of products, which provides you with a versatile graphics design and development environment for embedded Human Machine Interfaces (HMI).

With native support for the OpenGL® SC1 & SC2 (Safety Critical) and ES1 & ES2 (Embedded system) standards, ANSYS SCADE Display represents a new generation of graphics software development tools, spanning prototyping, display design, simulation, verification and validation, and certified code generation supporting several safety standards in a certifiable environment.

ANSYS SCADE Display is tightly integrated with SCADE Suite to provide a comprehensive development environment for both embedded HMIs and their behavioral logic.

FEATURES

  • Graphical Prototyping and Design
  • Refine HMI software with beavioral logic
  • Seamless integration with Ansys SACE Lifecycle for comprehensive Application Life Cycle Management
  • Supports simulation of graphical specifications in step-by-step ot continuous mode
  • SCADE automates design checks, ensuring compliance with rules and saving time with suggestions and corrections
  • Create and manage test cases, produce test scenarios and define expected results as pictures with inclusion/exclusion zones
  • Certification for Critical Safety Standards such as DO-178B & C, EN 50128, IEC 61508, and ISO 26262
  • Efficient code generation of readable, traceable and retargetable C code for embedded HMIs with support of OpenGL, SC1 & SC2, ES1 &ES2 standards
  • Build functional mock-ups and export them for use with Ansys Twin Builder program and all FMI-compliant simulation tools
